10 Amp 25mm Latching Push Button Switch Angel Eye LED Power Logo Waterproof Stainless Steel Round Self-Locking 1'' 1NO 1NC(Blue Red Green Yellow White)
SKU:
AP25AF11EZPS6BT
Availability:
In Stock
- $19.99
-
- $19.99
- Unit price
- per
Subtotal:
$19.99
10 customers are viewing this product
Free Shipping
Worldwide Free Shipping (Ordinary Delivery)
Orders over 500$ Fast Express Free
Description
xFeatures:
- GET NEW ONE IF NOT MAN MADE BROKEN IN 3 YEARS SINCE YOU PURCHASE THE SWITCH.
- Brand All New Design Silver 10A Stainless Steel Ring LED Power Logo Push button Switch; LED voltage: 12V only, Hole size required: 1''/25mm
- 25mm Latching Push Button Switch: Push it, ON; Push it again, OFF. Contact Configuration: 1NO1NC
- 4.8 mm wide X 0.8 mm thickness Terminal Pin for High Current Use; Longer work life: Electrical life: 500,000 times. Mechanical Life: 2,000,000 times.
- High quality metal material & IP65 waterproof protection can be used in wet or dusty enviroment.
Specification:
- Operation Temperature: -20 ℃ ~ +55℃- Mechanical life: 2,000,000 cycles
- Electrical life: 500,000 cycles
- Panel thickness: 1 - 10mm
- Protection level: IP65, IK10
- Mounting Cut Hole: 25mm
- Operation Type: Latching
- Switch Contact: 1NO 1NC
- LED Rating: 10 MA
- LED Pattern: Ring Indicator
- LED Life: 100,000 hours
- Contact Material: Silver alloy
- Button Material: Stainless Steel
Note:
- The switch come with a rubber O-ring whichmakes it splash resistant but it can NOT be submerged underwater.
Packing Include: 1 x All New Design 25mm push button switch,1 x pigtail socket
